D-LINK DGS-1210-52MP/E 48xGb POE 4xSFP Comb

Descripción y características de D-LINK DGS-1210-52MP/E 48xGb POE 4xSFP Comb

Marca
D-Link

Modelo
DGS-1210-52MP/E

Características
- Puertos 10/100 /1000BASE-TX: 48 puertos

- Puertos SFP: 4 Puertos

- Capacidad de switch: 104 Gbps

- Tamaño de la tabla de direcciones MAC: 16K

- Buffer de paquetes: 3 MB por dispositivo

- Consumo(Standby/Máximo): 48.9W / 483.1W (PoE)

- Dimensiones: 440 x 430 x 44 mm

- Peso: 5.78 kg

- Ventilación: Ventilador inteligente

- Temperatura:

Operación: -5° a 50°C (23° a 112°F)

Almacenamiento: -20° a 70°C (-4° a 158°F)

- Humedad

Operación: 0% ~ 95% sin condensación

Almacenamieno: 0% ~ 95% sin condensación

- Certificación: CE Class A, VCCI Class A, FCC

Class A, cUL, CE (LVD), BSMI, CCC, C-Tick

L2 Features

MAC Address Table

- 16K entries

IGMP Snooping

- IGMP v1/v2 Snooping

- Supports 256 IGMP groups

- Supports at least 64 static multicast addresses

- IGMP per VLAN

- Supports IGMP Snooping Querier

Loopback Detection

802.3ad Link Aggregation:

- DGS-1210 28/28P: Maximum of 14 groups/8 ports per group

- DGS-1210 52/52MP/52P: Maximum of 26 groups/8 ports per group

- DGS-1210 -10/10P: Maximum of 5 groups/8 ports per group

LLDP

LLDP-MED

Jumbo Frame

- Up to 9,216 bytes

Spanning Tree Protocol

- 802.1D STP

- 802.1w RSTP

Flow Control

- 802.3x Flow Control

- HOL Blocking Prevention

Port Mirroring

- One-to-One

- Many-to-One

- Supports Mirroring for Tx/Rx/Both

Multicast Filtering

- Forwards all unregistered groups

- Filters all unregistered groups

Configurable MDI/MDIX

- MLD snooping v1/v2 (256 groups)

VLAN

802.1Q

VLAN Group

- Max. 256 static VLAN groups

Configurable VID from 1 - 4094

Asymmetric VLAN

Auto Voice VLAN

- Max. 10 user-defined OUI

- Max. 8 default OUI

Auto Surveillance VLAN

Quality of Service (QoS)

802.1p Quality of Service

8 queues per port

Queue Handling

- Strict

- Weighted Round Robin (WRR)

Bandwidth Control

- Port-based (Ingress/Egress, min granularity 10/100/1000 is 64 Kbps)

QoS based on:

- 802.1p Priority Queues

- DSCP

- ToS

- IPv6 Traffic Class

- TCP/UDP port

Fecha Revisión
13-06-2022 por MPM
