D-Link DGS-1210-52/E Switch 52xGB 4xSFP Combo

Descripción y características de D-Link DGS-1210-52/E Switch 52xGB 4xSFP Combo

Marca
DLink

Modelo
DGS-1210-52/E

Interfaz
- 48 x Puertos 10/100/1000BASE-TX

- 4 x Puertos SFP

Rendimiento
- Capacidad del switch: 104 Gbps

- 64-Byte Packet Forwarding Rate: 77.4 Mpps

- MAC Address Table Size: 16K

- Packet Buffer: 3 MB por dispositivo

- Jumbo Frame: hasta 9,216 Bytes

Características
Funcionalidades L2

- MAC Address Table: 16K entries

- IGMP Snooping:

IGMP v1/v2 Snooping

Supports 256 IGMP groups

Supports at least 64 static multicast addresses

IGMP per VLAN

Supports IGMP Snooping Querier

- Loopback Detection

- 802.3ad Link Aggregation:

Maximum of 26 groups/8 ports per group

- LLDP

- LLDP-MED

- Jumbo Frame: Up to 9,216 bytes

- Spanning Tree Protocol: 802.1D STP

802.1w RSTP

- Flow Control: 802.3x Flow Control

HOL Blocking Prevention

- Port Mirroring: One-to-One

Many-to-One

Supports Mirroring for Tx/Rx/Both

- Multicast Filtering:

Forwards all unregistered groups

Filters all unregistered groups

- Configurable MDI/MDIX:

MLD snooping v1/v2 (256 groups)

VLAN

- 802.1Q

- VLAN Group

Max. 256 static VLAN groups

- Configurable VID from 1 - 4094

- Asymmetric VLAN

- Auto Voice VLAN

Max. 10 user-defined OUI

Max. 8 default OUI

- Auto Surveillance VLAN

Calidad de servicios (QoS)

- 802.1p Quality of Service

- 8 queues per port

- Queue Handling

Strict

Weighted Round Robin (WRR)

- Bandwidth Control

Port-based (Ingress/Egress, min granularity 10/100/1000 is 64 Kbps)

- QoS based on:

802.1p Priority Queues

DSCP

ToS

IPv6 Traffic Class

TCP/UDP port

Funcionalidades L3

- IP Interface

Supports 1 interface

- IPv6 Neighbor Discovery (ND)

Lista de conrol de acceso (ACL)

- Max. 50 access list

- Max. 768 rules shared by IPv4, MAC and IPv6

- Each rule can only be associated with a single port

- ACL based on

802.1p priority

VLAN

MAC address

- Ether type

- IP address

- DSCP

- Protocol type

- TCP/UDP port number

- IPv6 Traffic Class

Seguridad

- Broadcast/Multicast/Unicast Storm Control

- D-Link Safeguard Engine

- DHCP Server Screening

- IP-MAC-Port Binding (Smart Binding)

Supports 512 address binding entries

ARP Inspection

ARP + IP Inspection

Supports DHCP Snooping

- 802.1X Port-based Access Control

- ARP Spoofing Prevention

Max. 64 entries

- Traffic Segmentation

- SSH v2

- SSL

Supports v1/v2/v3

- Port Security

Supports up to 64 MAC addresses per port

- Duplicate address detection

AAA

- 802.1X Authentication

Supports local/RADIUS database

Supports port-based access control

Supports EAP, OTP, TLS, TTLS, PEAP

- IPv6 RADIUS Server

- Support MD5 authentication

Gestión

- Web-based GUI

- D-Link Network Assistant Utility

- Compact CLI

- Telnet Server

- TFTP Client

- Configurable MDI/MDIX

- SNMP

Supports v1/v2c/v3

- SNMP Trap

- Backup/Upgrade firmware

- Smart Wizard

- Upload/Download Configuration file

- System Log

Max. 500 log entries

- BootP/DHCP Client

- SNTP

- ICMP v6

- IPv4/v6 Dual Stack

- DHCP Auto Configuration

- Time Setting

SNTP

- RMONv1

- Trusted Host

Físicas
- Consumo (Standby/Max.): 29.49W / 38.27W

- Alimentación: 10 a 240 VAC, 50/60HZ fuente de alimentación interna

- Dimensiones (An x Prof x Alt): 440 x 210 x 44 mm

- Peso: 2.58 kg

- Ventilación: Ventiladores inteligentes

Fecha Revisión
13-06-2022 por MPM
